MDA462-1/2-5C-15/46-M956
Related products
Product detailed description
High accuracy, simple installation, repeatability and reliability
Our pressure sensors offer an efficient, accurate and durable solution for reliable and safe pressure measurement. These sensors are used in a number of industrial areas, where they control and measure melt pressure and ensure the optimal operation of production processes. Due to their resistance to the high temperatures and pressures typical of these applications, they are a suitable choice for a variety of uses. When selecting a sensor, it is important to consider the specific requirements of your application, such as the temperature range, pressure range, and materials with which the sensor will interact. The correct selection of the sensor guarantees reliable and accurate results and a long service life of the device without problems. Installing the sensor in the mounting hole of the production line is simple.
However, if you have doubts about the correct installation, do not hesitate to contact our technicians. We are ready to provide support and offer the ideal solution for your application.
Melt pressure sensors - With rigid rod and flexible capillary
Flexible capillary pressure sensors that are a superior solution ideal for use in environments with limited space or areas with high radiant heat from heating elements on production lines. An innovative design with extended sensor electronics located outside of the radiant heat area significantly reduces the risk of sensor damage.
Our flexible capillary is designed for maximum durability and flexibility, allowing for easy sensor installation and handling in harsh environments. It is important to carefully attach the sensor head to the included adapter, which is included in the package, and ensure that it is placed on a stable part of the machine away from areas with unwanted vibrations or shocks that could negatively affect the performance of the sensor.
For this series of sensors customization is possible according to your specific needs. We offer the option of choosing the length of the fixed rod as well as the flexible capillary, as well as the option of choosing the mounting thread. In addition, the sensor can be equipped with various optional features, such as the type of sensor cartridge or special coating, to ensure maximum durability and functionality in your specific industrial environment. This flexibility allows the sensor to be fully customized to your specific requirements, ensuring optimal integration and performance in a wide range of applications.
Take advantage of the consultation with our technicians who can help you choose the right sensor configuration for your applications.
Additional parameters
| Category: | Pressure Sensors |
|---|---|
| Accuracy: | ± 1.00% FSO |
| Process connection: | 1/2-20UNF |
| Pressure range: | 0-500 bar |
| Length of rigid stem: | 15 cm |
| Flexible capillary length: | 46 cm |
| Output signal: | 3.33mV/V |
Providing Innovative Solutions
For more than 60 years, with a commitment to helping customers, Dynisco has been providing tools and services for the polymer industry that offer its customers a 'window into the process' - an insight into the manufacturing process.
Today's customers need accurate information that allows them to verify and, if necessary, adjust their process to ensure that their products meet precise specifications. The information provided by Dynisco enables our customers to maintain a consistent process regardless of their global location.
Dynisco's portfolio represents a vast array of sensors (transducers), evaluation and display technology along with laboratory instruments with the possibility of online connection directly in production, thus providing you with the most accurate information about your production process in the market, in the field of measuring rheological properties of polymers, pressure, and temperature.
Dynisco provides our customers with the ability to compare data obtained from a pilot project with a laboratory environment with online production 24 hours a day. This data allows for immediate response and system adjustment in critical situations, ensuring that any deviations are immediately corrected to guarantee maximum quality at maximum performance.
History of Dynisco
Dynisco, known worldwide for top-notch products in pressure and temperature measurement and regulation for the plastic extrusion industry, has been developing innovative and high-quality solutions for plastic extrusion processing for 60 years and is founded on the expertise of engineers with an average of 15-20 years of experience. Dynisco's sensors, controls, and analytical instruments have proven to offer better control, reduce downtime, minimal scrap, and unmatched reliability and working life. Our commitment and ability to collaborate with you to help you measure, analyze, and equip extrusion control systems that meet your precise needs are unparalleled. From breakthrough technology in the most comprehensive range of sensors to renowned quality and performance in indicators, controls, and analytical tools.
Dynisco Sensors Dynisco was designed specifically for the robust environment of the plastics industry and has developed some of the most advanced solutions for measuring plastic extrusion, molding, and control applications. We produce a wide range of robust melt pressure sensors compatible with mV/V, mA, VDC, and HART thanks to engineering excellence based on expertise and experience.
Dynisco Analytical Instruments The quality of the process begins with the use of material. Dynisco's analytical tools enable the processor to verify material specification and optimize process conditions. These tools include flow Dynisco Heilbronn Facility in Germany
melt indexers, capillary rheometers, and small laboratory mixing extrusion systems. Dynisco also offers the most comprehensive and accurate range of on-line rheometers available on the market.
Dynisco offers a complete range of global services and technical support for our complete line. Dozens of highly qualified technical support workers are deployed internationally and provide:
Expert consultations Custom solution design On-site equipment diagnostics and troubleshooting Repairs and maintenance of transducers ∙ Installation services Equipment operation training ∙ System repairs, spare parts, preventive maintenance, and more
Customers from around the world have discovered that Dynisco is dedicated to product innovation and advanced system solutions that significantly impact the efficiency of manufacturing processes.
